12m Decorative Smart Street Light Pole for Ethiopia

SUNLUX supplies a 12-meter decorative dual-arm smart street lighting pole for urban roads, boulevards, municipal infrastructure and commercial developments in Ethiopia. The design integrates LED lighting and embedded decorative light strips, with a maintenance access door and galvanized steel construction.

Technical Specifications

Overall height	12 meters
Pedestrian light height	11 meters
Material	Q235 steel
Finish	Hot-dip galvanized and plastic sprayed; color to be determined
Main pole	160 × 160 mm square tube; 4 mm wall thickness
Upper main pole	80 × 160 mm rectangular tube; 3 mm wall thickness
Flange	450 × 450 × 16 mm
Maintenance door	Below the lamp post
Embedded light strips	Two side strips, 5 meters each
Lighting design	Two integrated LED lamp arms; drawing labels each LED module as 300W
Arm reach	1500 mm each side, per drawing

Engineering note: Specifications above are transcribed from the supplied description and drawing. Final luminaire electrical rating, structural design, foundation and wind-load compliance must be confirmed in the approved project drawings.

Applications in Ethiopia

Suitable for specification review in Addis Ababa, Dire Dawa and other Ethiopian urban road, streetscape and smart city lighting projects. SUNLUX offers factory-direct OEM/ODM production and engineering drawing support for contractors, developers and municipal buyers.

Request a Quotation

Send your project BOQ, required quantity, wind speed, installation location and lighting requirements to SUNLUX for a project-specific quotation and technical confirmation.
